To buy a spare inner tube for a 20×4 e-bike tyre, match the complete size on the fitted tyre, the tube maker's supported size range, the valve and any tyre insert. A listing that says only “20 inch” does not give you enough information. Even “406” leaves the tyre width unanswered.
The examples below help you reject unsuitable sizes and recognise a possible match before paying. They cover an existing tyre-and-tube setup, without a volume-occupying insert unless stated. They are specification comparisons, not installation tests or approval of a replacement for a particular bike.
Start with the tyre you actually have
Photograph the tyre's size marking and the valve where it emerges from the rim. If the old tube or its packaging is accessible, keep a photo of its full specification too. There is no need to dismantle a sound wheel just to read its tyre sidewall.
Suppose your fitted tyre says 100-406. In this ETRTO marking, 100 is the nominal tyre width in millimetres; 406 identifies the matching rim bead-seat diameter. This is our worked example, not a claim that every 20×4 tyre—or every Wallke tyre—has that marking.
Use those two numbers when checking a tube's supported sizes. Do not turn 4 inches into 101.6 mm and assume you have established the tyre's actual specification. The marking on the fitted tyre is the useful starting point. If it is unreadable, send photos of the tyre, valve and bike version to support before ordering; do not fill in the missing size from the model name alone.
Three real specifications: reject, reject, size candidate
Here is what happens when three published manufacturer specifications are compared with that 100-406 tyre, with no volume-occupying insert.
On a small screen, scroll the comparison sideways.
| Documented tube specification | Decision for this example | Reason |
|---|---|---|
| Continental Compact 20, normal: 32-406 → 47-451 | Reject | The documented width range stops at 47 mm. It does not cover the example's 100 mm width, even though 406 appears. |
| Continental Compact 20, Wide: 50-406 → 62-406 | Reject | “Wide” here reaches 62 mm, not 100 mm. The name is not a substitute for the numbers. |
| Schwalbe 7XXL, product 10464930: 90–120-406, AV, 40 mm | Size candidate; check valve and installation | 100 lies between 90 and 120, and 406 is listed. That clears this size comparison, not every compatibility requirement. |
The first two examples come from Continental's published tube catalogue; the third is a specific Schwalbe product listing. They are worked examples, not a ranking, stock check or recommendation to buy those products. Specifications were checked on 23 October 2026; compare the exact item offered for sale before ordering.
Notice that the normal Compact 20 range includes both 406 and 451. Some inner tubes are expressly specified for more than one diameter. A replacement tyre must match the rim's bead-seat diameter; a flexible inner tube must cover the fitted tyre's size in its maker's stated range. Do not apply a blanket “406 and 451 never mix” rule to all inner tubes, or assume every size between catalogue endpoints is supported.
For the example above, you can already discard the two narrow tubes. You do not need to buy one to find out whether it will stretch far enough. A seller's promise that a tube is “heavy duty” does not resolve a missing size specification either.
Finish the check at the valve
The 7XXL example specifies AV, the automotive-style Schrader valve. SV identifies the slimmer Presta type. Match the valve actually fitted to your wheel, and confirm the replacement's stated stem length and shape.
A practical check has three parts:
- Type: compare the old valve or its label with the exact replacement option. A suitable tube size with the wrong valve is an unresolved purchase.
- Length: use the old tube's specification where available. The visible stem outside the rim is not necessarily the advertised total length: Schwalbe, for example, includes the valve foot in its measurement.
- Access: make sure the proposed stem can be used with your rim and pump head. If it differs from the working original, get that combination confirmed before ordering.
“AV 40 mm” describes the example product. It is not a universal valve specification for Wallke bikes.
If you have a tyre insert, pause the ordinary size comparison
A thick insert occupying space around the tube can change the required tube size. Identify the insert and its size before using smaller-tube advice. This exception concerns an insert such as Armour, not simply the rim tape covering spoke holes.
There is a concrete reason to avoid a universal downsizing rule. When checked on 23 October 2026, Tannus America's chart paired its 20×3.0–4.0 Armour row with a 20×2.5–3.0 tube. Tannus UK's comparable fat-tyre row gave 20×2.5–3.5. The tannus.com support table showed 20×3.0–4.0 for its 20×3.0–4.0 row.
Those published ranges differ; the reason is not established here. They do not tell us which applies to the insert in your wheel. If the supplied instructions and a web chart conflict, send the insert maker a photo of its size/SKU label and both instructions, and request confirmation of the tube specification for your setup. Do not choose a middle value or borrow another rider's combination.
Without an insert, this is not a reason to substitute a narrower tube outside its stated tyre-size range.
Check your Wallke version before ordering
The Wallke EU homepage checked for this guide lists 20×4 tyres for H7 AWD and H9 AWD, while Titan X1 AWD is listed with 20×5 tyres. A search result for a 20×4 spare is therefore not automatically relevant to every current Wallke model.
These are nominal model-page descriptions. Your fitted tyre's marking, wheel and configuration still decide the parts enquiry. This guide has not verified a universal Wallke ETRTO marking, valve length or third-party tube approval.
Inflation is a separate decision from tube size. Once the correct replacement has been identified, use the fitted tyre, rim and bike limits when setting pressure; Wallke's fat-tyre pressure guide explains the setup considerations.
Turn an incomplete listing into a precise question
For the worked example, a useful enquiry would be:
My fitted tyre is marked 100-406 and uses an inner tube without a tyre insert. I need a replacement with the same valve type and suitable stem length as the original shown in these photos. Does this exact tube SKU cover 100-406? Please confirm its valve specification; the listing only says “20 inch”.
If an insert is fitted, add its exact size/SKU and the applicable installation instructions. For a Wallke parts enquiry, use Wallke support with the model/version and photos of the actual tyre and valve.
Before you order, you should have one of three answers: reject because the published range excludes your tyre; candidate because size matches but a valve or configuration detail remains; or confirmed specification match once the exact item and remaining details have been checked. Buy the spare on that evidence, before a puncture forces a last-minute guess.
